SMD2121 P3 standard die cast aluminum cabinet indoor full color Haning led display
SCXK electronic Co.,ltd has the standard new factory,about 300 employees.We are standard R&D department
and after-sales service workers.And separately design ability.
Our product mainly included led indoor full color led display.led outdoor display.
Die cast aluminum cabinet led display and stage led display. Floor led display.curtain led display.
Transparent led display.and so on
we always take the principle that is : professional makes good quality,good price product market
to provide perfect product and service for our customers.
| The indoor P3 full color led display parameter |
| LED Lamps | Type | SMD212(High Brightness LEDs) |
| LED Standard | Real Pixel(1R1G1B) |
| Red Wavelength | 625-630nm |
| Green Wavelength | 515-530nm |
| Blue Wavelength | 465-475nm |
| LED Module | Pixel Pitch | 3mm |
| Module Size | 192mm x192mm |
| Module Resolution | 64*64dots |
| LED Cabinet | Cabinet Size | 576mmX576mm |
| Cabinet Resolution | 192pixes *192pixels |
| Cabinets Material | die cast aluminum cabinet |
| led screen | Pixel Density | 111111pixels/sq.m |
| Drive IC | MBI5124 |
| Power Supply | Series connection |
| Brightness | >2300cd/sqm |
| Display Color | 16.7million |
| Viewing Angle | 160°(Horizontal),110°(Vertical) |
| Best Viewing Distance | 3m~200m |
| Max Power Consumption | 600 w/sq.m |
So far ,our die cast aluminum cabinet include all kinds of the style. The parameter as follows.
| The outdoor die cast aluminum cabinet hanging and rental usage led display(outdoor usage) |
| Number | Drive mode | module size | Resolution | cabinet size | Led standard | pixel density |
| P3.91 | 1/8 scan | 250x250mm | 64x64 | 500x500mm | 3 in 1 | 65410 |
| p4 | 1/8 scan | 256x128mm | 64x32 | 512x512mm | 3 in 1 | 62500 |
| P4.81 | 1/8 scan | 250x250mm | 52x52 | 500x500mm | 3 in 1 | 43222 |
| P5 | 1/8 scan | 320x160mm | 64x32 | 640x640mm | 3 in 1 | 40000 |
| p6 | 1/8 scan | 192x192mm | 32x32 | 576x576mm | 3 in 1 | 27777 |
| p8 | 1/8 scan | 256x128mm | 32x16 | 512x512mm | 3 in 1 | 15625 |
| p10 | 1/4scan | 320x160mm | 32x16 | 640x640mm | 3 in 1 | 100000 |
| The indoor die cast aluminum cabinet hanging and rental usage led display |
| P2 | 1/32scan | 128X64mm | 64x32 | 512x512mm | 3 in 1 | 250000 |
| p2.5 | 1/32scan | 160x160mm | 64x64 | 480x480mm | 3 in 1 | 160000 |
| p3 | 1/32scan | 192x192mm | 64x64 | 576x576mm | 3 in 1 | 111111 |
| p4 | 1/32scan | 256x128mm | 64x32 | 512x512mm | 3 in 1 | 62500 |
| p5 | 1/16scan | 320x160mm | 64x32 | 640x640mm | 3 in 1 | 40000 |
| p6 | 1/16scan | 192x192mm | 32x32 | 576x576mm | 3 in 1 | 27777 |
We insist high top -level factory management and guarantee all process can meet the quality requirements.
1. Diversified products :
Varieties of models for outdoor/indoor LED display screens,and customized cabinets available,meet all requirements and win more profits for customers.
2. Experienced&Professional:
10 years manufacturing experience on LED displays, professional workmanship & design.
3. Best raw materials:
Taiwan Epistar LED chip,high quality,high brightness and long life span.
4. Competitive price:
100% factory price,competitive and reasonable price.
5. Strict quality control:
100% testing before packing , make sure our quality before delivery.
6. Quality gurantee:
All our LED display screens is more than 100,000 hours life span.
If you have any question or confusion,just feel free to contact us.And we will be glad to provide any assistance to you.
Our group will be always here to service you.Any feedback will be highly appreciated.
